CUB CADET ULTIMA Z SERIES

Z1 42 IP

Answer the call of large properties and varying terrain with the Ultima Series Z1 42 42-in. 547cc Zero-Turn Lawn Mower with IntelliPOWER®. Engineered to tackle hills and slopes up to 15-degrees, you can save time mowing with an Ultima Series™ zero-turn that’s 25% faster than a tractor**.

Featuring an IntelliPOWER® Engine to deliver up to 18% more available power*, for less bogging down when mowing in challenging conditions

IntelliPOWER® Engines deliver up to 18% more available power*, resulting in less bogging down when mowing in challenging conditions like tall, thick, or wet grass.

42-in. steel cutting deck with smooth arc dual-blades, cut overlap, and deep dome deck design provides flawless results, mows a wide area of grass to help reduce cutting time, is rust-resistant, and provides your lawn with a signature cut.
Protect against wear and tear while being the envy of your neighborhood with a continuous, 2×2 tubular steel frame designed to withstand heavy loads and provide stability on rough, uneven terrain.
Precision trimming offset front casters align with blade edge for trimming precision while maintaining line-of-sight and stable balance

SPECIFICATIONS:

Engine

Engine BrandCub Cadet®
Engine ModelIntelliPOWER®
Engine Model NumberAX90Z0
Engine Displacement547cc
Starter TypeElectric
Fuel Tank Capacity3.5 gal. US (13.25 L)
CylindersSingle
Engine StartIgnition Key
Engine Oil Capacity1.8 qt. US (1.7 L)
LubricationFully pressurized
Charging System12 amp regulated
Fuel GaugeNo
GovernorElectronic
ChokeElectronic
Air FilterDual element
Oil FilterYes
Fuel DeliveryCarburetor

Battery

Battery230 CCA
Battery TypeLead Acid
Battery Voltage12V

Drive System

TransmissionHydro-Gear EZT 2200
Forward Speed7 MPH / 11.3 km/h
Reverse Speed3.5 MPH / 5.6 km/h
Drive SystemHydrostatic
Serviceable TransmissionNo (Maintenance-Free)

Cutting Deck

Deck Cutting Width42 in
Deck WashYes
Deck Material13-gauge steel
Deck Engagement (PTO)Electric
Deck ConstructionStamped
Blade(s)Two
Deck LiftFoot pedal with Dial Adjust
Cutting Height Range1” – 4.5”
Anti-ScalpingTwo gauge wheels
Deck Positions15

Chassis

Frame2” x 2” tubular steel
Turning Radius0°
ROPSNo
Rear Tow HitchNo
Corrosion ProtectionYes
Front Caster Yokes1/4″ Steel

Controls

Cruise ControlNo
BrakesDisc
Steering ControlLap Bars

Comfort

Seat Type18″ high back
ArmrestsNo
Seat AdjustmentKnob
Front Caster SuspensionNo

Wheels

Rear Tires20”x 8”-8″
Front Tires11″x 6.0″-5″
Tire TreadTurf Master / Multi Trac

Specifications

SeriesUltima Series™ Z

Additional Specifications

Hour MeterAvailable Separately
Mulch KitAvailable separately
Headlight(s)No
Cup HolderYes
Operator Presence SystemYes
Parking BrakeLap Bar Integrated
Model Number17ALEACS010

Warranty

Residential Warranty3-year unlimited hours
Frame WarrantyLifetime Limited
Deck Shell Warranty3-year unlimited hours
Commercial WarrantyNo

Disclaimers

Specifications:
Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from.
IntelliPOWER®*:
When compared to a Cub Cadet® 547cc engine without IntelliPOWER® feature (4X90HW). Improvements vary depending on engine models and specific operating conditions.
Efficiency**:
Mowing identical grass conditions using a 42-inch Ultima Series zero-turn mower at a speed of 7 MPH vs. a Cub Cadet® 42-inch lawn tractor at a speed of 5 MPH.
